Concept Libraries for Automatic Electronic Health Record Based Phenotyping: A Review
Main Article Content
Abstract
Introduction
Electronic health records (EHR) are linked together to examine disease history and to undertake research into the causes and outcomes of disease. However, the process of constructing algorithms for phenotyping (e.g., identifying disease characteristics) or health characteristics (e.g., smoker) is very time consuming and resource costly. In addition, results can vary greatly between researchers. Reusing or building on algorithms that others have created is a compelling solution to these problems. However, sharing algorithms is not a common practice and many published studies do not detail the clinical code lists used by the researchers in the disease/characteristic definition. To address these challenges, a number of centres across the world have developed health data portals which contain concept libraries (e.g., algorithms for defining concepts such as disease and characteristics) in order to facilitate disease phenotyping and health studies.
Objectives
This study aims to review the literature of existing concept libraries, examine their utilities, identify the current gaps, and suggest future developments.
Methods
The five-stage framework of Arksey and O'Malley was used for the literature search. This approach included defining the research questions, identifying relevant studies through literature review, selecting eligible studies, charting and extracting data, and summarising and reporting the findings.
Results
This review identified seven publicly accessible Electronic Health data concept libraries which were developed in different countries including UK, USA, and Canada. The concept libraries (n = 7) investigated were either general libraries that hold phenotypes of multiple specialties (n = 4) or specialized libraries that manage only certain specialities such as rare diseases (n = 3). There were some clear differences between the general libraries such as archiving data from different electronic sources, and using a range of different types of coding systems. However, they share some clear similarities such as enabling users to upload their own code lists, and allowing users to use/download the publicly accessible code. In addition, there were some differences between the specialized libraries such as difference in ability to search, and if it was possible to use different searching queries such as simple or complex searches. Conversely, there were some similarities between the specialized libraries such as enabling users to upload their own concepts into the libraries and to show where they were published, which facilitates assessing the validity of the concepts. All the specialized libraries aimed to encourage the reuse of research methods such as lists of clinical code and/or metadata.
Conclusion
The seven libraries identified have been developed independently and appear to replicate similar concepts but in different ways. Collaboration between similar libraries would greatly facilitate the use of these libraries for the user. The process of building code lists takes time and effort. Access to existing code lists increases consistency and accuracy of definitions across studies. Concept library developers should collaborate with each other to raise awareness of their existence and of their various functions, which could increase users’ contributions to those libraries and promote their wide-ranging adoption.
Article Details
References
Paraskevas Vezyridis ST. Open access research evolution of primary care databases in UK: a scientometric analysis of research output. BMJ Open [Internet]. 2016; Available from:
1136/bmjopen-2016-012785https://doi.org/10.1136/bmjopen-2016-012785
SAIL databank. Increase innovation with data linkage. Retrieved January 28, 2020, from
Morley KI, Wallace J, Denaxas SC, Hunter RJ, Patel RS, et al. Defining disease phenotypes using national linked electronic health records: A Case study of atrial fibrillation. 2014; 9.
1371%2Fjournal.pone.0110900https://doi.org/10.1371%2Fjournal.pone.0110900
Lu M, Rupp LB, Trudeau S, Gordon SC. Validity of an automated algorithm using diagnosis and procedure codes to identify decompensated cirrhosis using electronic health records. 2017; 369–76.
2147/CLEP.S136134https://doi.org/10.2147/CLEP.S136134
Makarov A, Kontopantelis E, Sperrin M, Stocks SJ, Williams R, Rodgers S, et al. Primary care medication safety surveillance with integrated primary and secondary care electronic health records: A cross-sectional study. Drug Saf. 2015; 38(7):671–82.
Nicholson A, Tate AR, Koeling R CJ. What does validation of cases in electronic record databases mean? The potential contribution of free text. Wiley Online Libr. 2011 ;( Ci):321–4.
https//doi.org/10.1002/pds.2086
Newton KM, Peissig PL, Kho AN, Bielinski SJ, Berg RL, Choudhary V, et al. Validation of electronic medical record-based phenotyping algorithms: Results and lessons learned from the eMERGE network. J Am Med Informatics Assoc. 2013; 20(E1):147–54.
1136%2Famiajnl-2012-000896https://doi.org/10.1136%2Famiajnl-2012-000896
Pendergrass SA, Crawford DC. Using electronic health records to generate phenotypes for research. Curr Protoc Hum Genet. 2019; 100(1):1–20.
1002%2Fcphg.80https://doi.org/10.1002%2Fcphg.80
Springate DA, Kontopantelis E, Ashcroft DM, Olier I, Parisi R, Chamapiwa E, et al. ClinicalCodes: An online clinical codes repository to improve the validity and reproducibility of research using electronic medical records. 2014; 9(6):6–11. https://dx.doi.org/10.1371%2Fjournal.pone.0099825
Bhattarai N, Charlton J, Rudi sill C, Gulliford MC. Coding, recording and incidence of different forms of coronary heart disease in primary care. PLoS One. 2012; 7(1).
1371%2Fjournal.pone.0029776https://doi.org/10.1371%2Fjournal.pone.0029776
Gulliford MC, Charlton J, Ashworth M, Rudd AG, Toschke AM. Selection of medical diagnostic codes for analysis of electronic patient records. Application to stroke in a primary care database. PLoS One. 2009; 4(9): e7168. https://dx.doi.org/10.1371%2Fjournal.pone.0007168
Morley KI, Wallace J, Denaxas SC, Hunter RJ, Patel RS, Perel P, et al. Defining disease phenotypes using national linked electronic health records: A case study of atrial fibrillation. PLoS One. 2014; 9(11).
https://dx.doi.org/10.1371%2Fjournal.pone.0110900
Ostapyk T. Manitoba Centre for Health Policy Data Repository. In: Michalos AC (eds) Encyclopedia of quality of life and well-being research. Springer, Dordrecht; 2014.
1007/978-94-007-0753-5_3483https://doi.org/10.1007/978-94-007-0753-5_3483
Arksey H, O’Malley L. Scoping studies: Towards a methodological framework. Int J Soc Res Methodol Theory Pract. 2005; 8(1):19–32.
1080/1364557032000119616https://doi.org/10.1080/1364557032000119616
Tryka KA, Hao L, Sturcke A, Jin Y, Wang ZY, Ziyabari L, et al. NCBI’s database of genotypes and phenotypes: DbGaP. Nucleic Acids Res. 2014; 42(D1):975–9.
1093%2Fnar%2Fgkt1211https://doi.org/10.1093%2Fnar%2Fgkt1211
Denaxas SC, George J, Herrett E, Shah AD, Kalra D, Hingorani AD, et al. Data resource profile: Cardiovascular disease research using linked bespoke studies and electronic health records (CALIBER). Int J Epidemiol. 2012; 41(6):1625–38.
1093%2Fije%2Fdys188https://doi.org/10.1093%2Fije%2Fdys188
RD-Connect. Bioinformatic tools. Retrieved from:
https://rd-connect.eu/what-we-do/bioinformatic-tools/
Kirby JC, Speltz P, Rasmussen L V., Basford M, Gottesman O, Peissig PL, et al. PheKB: A catalog and workflow for creating electronic phenotype algorithms for transportability. J Am Med Informatics Assoc. 2016; 23(6):1046–52.
1093%2Fjamia%2Focv202https://doi.org/10.1093%2Fjamia%2Focv202
University of Manchester Institute of Population Health. Clinicalcodes.org (n.d. para. 4). Clinicalcodes.org. Retrieved January 28, 2020, from
https://clinicalcodes.rss.mhs.man.ac.uk/
University of Manitoba. (n.d. para. 1, 2). Concept dictionary and glossary for population based research. Retrieved January 29, 2020, from
Denaxas S, Gonzalez-Izquierdo A, Direk K, Fitzpatrick NK, Fatemifar G, Banerjee A, et al. UK phenomics platform for developing and validating electronic health record phenotypes: CALIBER. J Am Med Inform Assoc. 2019; 26(12):1545–59.
1093%2Fjamia%2Focz105https://doi.org/10.1093%2Fjamia%2Focz105
Kamat MA, Blackshaw JA, Young R, Surendran P, Burgess S, Danesh J, et al. PhenoScanner V2: an expanded tool for searching human genotype-phenotype associations. Bioinformatics. 2019; 35(22):4851–3.
1093%2Fbioinformatics%2Fbtz469https://doi.org/10.1093%2Fbioinformatics%2Fbtz469
Information Engineering Branch, National Centre for Biotechnology Information, USA. (n.d. para.1). dbGaP Overview. Retrieved January 30, 2020, from
https://www.ncbi.nlm.nih.gov/projects/gap/cgi-bin/about.html
RD-Connect. (n.d. para 1). RD-Connect. Retrieved from
https://platform.rd-connect.eu/
Thompson R, Johnston L, Taruscio D, Monaco L, Béroud C, Gut IG, et al. RD-connect: An integrated platform connecting databases, registries, biobanks and clinical bioinformatics for rare disease research. J Gen Intern Med. 2014; 29(SUPPL. 3):780–7.
1007%2Fs11606-014-2908-8https://doi.org/10.1007%2Fs11606-014-2908-8
Smith, M1, Turner, K1, Bond, R1, Kawakami, T1, and Roos L. The Concept Dictionary and Glossary at MCHP: Tools and techniques to support a population research data repository. 2019; 0(December):1–4.
23889/ijpds.v4i1.1124https://doi.org/10.23889/ijpds.v4i1.1124
Shah A. CALIBERcodelists user guide. 2014; 1–23. Available from:
Cardiovascular Epidemiology Unit, University of Cambridge. (n.d para 3.). PhenoScanner V2, Licence. Retrieved from
http://www.phenoscanner.medschl.cam.ac.uk/about/
University of Manitoba. (n.d. para. 1). Concept Dictionary and Glossary for Population Based Research. Retrieved January 31, 2020, from
RD-Connect. (n.d. para 1, 4). Genome-Phenome Analysis Platform. Retrieved January 31, 2020, from
https://rd-connect.eu/what-we-do/omics/gpap/
Wong KM, Langlais K, Tobias GS, et al. The dbGaP data browser: A new tool for browsing dbGaP controlled-access genomic data. Nucleic Acids Res. 2017;45(D1):D819-D826.
